On the Job Training (OJT) is the Best Training Method

OJT Instrumentation Sizing For Control Valve,Flow Element & Relief Device (using INSTRUCALC)

For : Engineering Physics, Instrumentation, Electronics Engineering

Instrucalc training: size control valves, orifices and PSVs.

4 modules · 12 lessons · 100% online

Part of the OJT Instrument Engineer Complete Package · 2 OJT
See Package Options

Mentor: M.Riandi, ST

About this OJT

Learn straight from real projects with OJT Instrumentation Sizing For Control Valve,Flow Element & Relief Device (using INSTRUCALC)

This Online OJT trains you to design and understand the operating principles of Control Valves, Flow Orifices and Pressure Relief Valves in an Oil & Gas Plant using INSTRUCALC.

After completing this Online OJT, participants will be able to:

  1. Understand the function of Control Valves, Flow Orifices and Pressure Relief Valves in a process system
  2. Calculate and size a Control Valve, Flow Orifice & Pressure Relief Valve according to process requirements
  3. Prepare a Calculation Report for Control Valves, Flow Orifices and Pressure Relief Valves
  4. Select instruments based on vendor catalogues

Curriculum

What you'll learn

4 modules · 12 lessons. Tap each part to see its lessons.

Module 1 Control Valve 5 lessons
  1. Control Valve in Process Plant
  2. Basic Operation of Control Valve
  3. Control Valve Sizing and Calculation
  4. Sizing and Calculation using INSTRUCALC
  5. Report Preparation
Module 2 Flow Orifice 3 lessons
  1. Flow Orifice Principles
  2. Sizing and Calculation using INSTRUCALC
  3. Report Preparation
Module 3 Pressure Reliev Valve 3 lessons
  1. Basic Operation of Pressure Relief Valve
  2. Sizing and Calculation using INSTRUCALC
  3. Report Preparation
Final Project Final Project 1 lessons
  1. Instrument Sizing and Calculation Report Preparation for Test Separator System in Wellhead Platform

How It Works

From first lesson to certificate

See the 7 learning steps

  1. Participants have installed Instrucalc on their own laptop

  2. Download the video lessons and (real) project data for practice from the link we give you

  3. Study all materials and follow the steps explained in the videos

  4. Follow the case modelling exercises in Instrucalc and the spreadsheets

  5. Complete the final project taken from a real project and consult it via WhatsApp/email

  6. Send your project file to the mentor's email for review

  7. Once you finish the final project, your certificate is sent by post.

Choose a package

One skill, or fully job-ready?

A single OJT gives you one skill. The Complete Package gives you every skill companies look for in this position, in one payment and at a lower price.

Complete Package Best value

OJT Instrument Engineer Complete Package

The right choice if your goal is to work as Instrument Engineer: no skill left behind, one single payment.

2 OJT programs at once: every skill you need to work as Instrument Engineer.

  1. Instrumentation Sizing For Control Valve,Flow Element & Relief Device (using INSTRUCALC) this OJT
  2. Instrumentation Design For Oil Gas Plant

Rp 4.000.000 Rp 3.500.000 Save Rp 500.000 (13%)

Get the Complete Package
Ask admin
